Тройники
Тройник стальной (ГОСТ 17376-2001) применяется в трубопроводах для отвода части транспортируемой трубопроводом среды другому элементу схемы.
| DN | D | D1 | T1 | F | H | r не менее | Масса, кг | |
|---|---|---|---|---|---|---|---|---|
| 40 | 45 | 2,5 | - | - | 40 | 40 | 5 | 0,3 |
| 4,0 | 4,0 | |||||||
| 5,0 | 0,4 | |||||||
| 50 | 57 | 3,0 | 45 | 2,5 | 50 | 45 | 0,4 | |
| 4,0 | 3,0 | 0,6 | ||||||
| 5,0 | 4,0 | 0,7 | ||||||
| 3,0 | - | - | 0,4 | |||||
| 4,0 | 0,6 | |||||||
| 5,0 | 0,7 | |||||||
| 65 | 76 | 3,5 | 45 | 2,5 | 65 | 60 | 0,8 | |
| 6,0 | 4,0 | 1,4 | ||||||
| 7,0 | 5,0 | 1,6 | ||||||
| 3,5 | 57 | 3,0 | 0,8 | |||||
| 6,0 | 5,0 | 1,4 | ||||||
| 7,0 | 5,5 | 1,6 | ||||||
| 3,5 | - | - | 0,8 | |||||
| 6,0 | 1,4 | |||||||
| 7,0 | 1,6 | |||||||
| 80 | 89 | 3,5 | 57 | 3,0 | 80 | 70 | 1,5 | |
| 6,0 | 4,0 | 2,0 | ||||||
| 8,0 | 5,5 | 2,7 | ||||||
| 3,5 | 76 | 3,5 | 1,5 | |||||
| 6,0 | 6,0 | 2,0 | ||||||
| 8,0 | 7,0 | 2,7 | ||||||
| 3,5 | - | - | 1,5 | |||||
| 6,0 | 2,0 | |||||||
| 8,0 | 2,7 | |||||||
| 100 | 108 | 4,0 | 76 | 3,5 | 100 | 80 | 2,2 | |
| 6,0 | 5,0 | 3,3 | ||||||
| 8,0 | 6,0 | 4,5 | ||||||
| 9,0 | 7,0 | 4,9 | ||||||
| 4,0 | 89 | 4,0 | 2,2 | |||||
| 6,0 | 6,0 | 3,3 | ||||||
| 8,0 | 8,0 | 4,5 | ||||||
| 9,0 | 8,0 | 4,9 | ||||||
| 4,0 | - | - | 2,2 | |||||
| 6,0 | 3,3 | |||||||
| 8,0 | 4,5 | |||||||
| 9,0 | 4,9 | |||||||
| 125 | 133 | 4,0 | 89 | 3,5 | 110 | 95 | 6 | 2,9 |
| 6,0 | 5,0 | 4,1 | ||||||
| 8,0 | 6,0 | 5,9 | ||||||
| 10,0 | 8,0 | 6,8 | ||||||
| 12,0 | 9,0 | 8,0 | ||||||
| 4,0 | 108 | 4,0 | 2,9 | |||||
| 6,0 | 4,1 | |||||||
| 8,0 | 5,9 | |||||||
| 10,0 | 6,8 | |||||||
| 12,0 | 8,0 | |||||||
| 4,0 | - | - | 2,9 | |||||
| 6,0 | 4,1 | |||||||
| 8,0 | 5,9 | |||||||
| 10,0 | 6,8 | |||||||
| 12,0 | 8,0 | |||||||
| 150 | 159 | 4,5 | 108 | 4,0 | 130 | 110 | 4,8 | |
| 6,0 | 5,0 | 6,6 | ||||||
| 8,0 | 6,0 | 9,0 | ||||||
| 10,0 | 9,0 | 10,1 | ||||||
| 12,0 | 10,0 | 12,2 | ||||||
| 4,5 | 133 | 4,0 | 4,8 | |||||
| 6,0 | 5,0 | 6,6 | ||||||
| 8,0 | 6,0 | 9,0 | ||||||
| 10,0 | 10,0 | 10,1 | ||||||
| 12,0 | 12,0 | 12,2 | ||||||
| 4,5 | - | - | 4,8 | |||||
| 6,0 | 6,6 | |||||||
| 8,0 | 9,0 | |||||||
| 10,0 | 10,1 | |||||||
| 12,0 | 12,2 | |||||||
| 200 | 219 | 6,0 | 133 | 5,0 | 160 | 140 | 10 | 10,2 |
| 8,0 | 6,0 | 13,8 | ||||||
| 10,0 | 8,0 | 16,8 | ||||||
| 12,0 | 10,0 | 19,9 | ||||||
| 16,0 | 16,0 | 26,6 | ||||||
| 6,0 | 159 | 6,0 | 10,2 | |||||
| 8,0 | 6,0 | 13,8 | ||||||
| 10,0 | 8,0 | 16,8 | ||||||
| 12,0 | 11,0 | 19,9 | ||||||
| 16,0 | 12,0 | 26,6 | ||||||
| 6,0 | - | - | 10,2 | |||||
| 8,0 | 13,8 | |||||||
| 10,0 | 16,8 | |||||||
| 12,0 | 19,9 | |||||||
| 16,0 | 26,6 | |||||||
| 250 | 273 | 7,0 | 159 | 4,5 | 190 | 175 | 12 | 18,4 |
| 10,0 | 6,0 | 26,0 | ||||||
| 12,0 | 8,0 | 31,2 | ||||||
| 16,0 | 11,0 | 41,6 | ||||||
| 18,0 | 12,0 | 46,8 | ||||||
| 7,0 | 219 | 6,0 | 18,4 | |||||
| 10,0 | 8,0 | 26,0 | ||||||
| 12,0 | 10,0 | 31,2 | ||||||
| 16,0 | 12,0 | 41,6 | ||||||
| 18,0 | 16,0 | 46,8 | ||||||
| 7,0 | - | - | 18,4 | |||||
| 10,0 | 26,0 | |||||||
| 12,0 | 31,2 | |||||||
| 16,0 | 41,6 | |||||||
| 18,0 | 46,8 | |||||||
| 300 | 325 | 8,0 | 219 | 6,0 | 220 | 200 | 15 | 27,4 |
| 10,0 | 8,0 | 34,2 | ||||||
| 12,0 | 10,0 | 41,1 | ||||||
| 16,0 | 12,0 | 54,8 | ||||||
| 22,0 | 16,0 | 75,3 | ||||||
| 8,0 | 273 | 7,0 | 27,4 | |||||
| 10,0 | 10,0 | 34,2 | ||||||
| 12,0 | 12,0 | 12,0 | ||||||
| 16,0 | 16,0 | 54,8 | ||||||
| 22,0 | 18,0 | 75,3 | ||||||
| 8,0 | - | - | 27,4 | |||||
| 10,0 | 34,2 | |||||||
| 12,0 | 41,1 | |||||||
| 16,0 | 54,8 | |||||||
| 22,0 | 75,3 | |||||||
| 350 | 377 | 10,0 | 273 | 7,0 | 240 | 225 | 15 | 46,0 |
| 12,0 | 10,0 | 55,2 | ||||||
| 16,0 | 12,0 | 73,6 | ||||||
| 20,0 | 16,0 | 92,0 | ||||||
| 10,0 | 325 | 8,0 | 46,0 | |||||
| 12,0 | 10,0 | 55,2 | ||||||
| 16,0 | 16,0 | 73,6 | ||||||
| 20,0 | 18,0 | 92,0 | ||||||
| 10,0 | - | - | 46,0 | |||||
| 12,0 | 55,2 | |||||||
| 16,0 | 73,6 | |||||||
| 20,0 | 92,0 |
